*Low start up speed for different wind speed areas, high wind energy utilization.
*Easy installation, flange connection.
*Blades using new art of precision injection molding, matched with optimized aerodynamic shape and structure, which enhance the wind energy utilization and annual output.
*Body of casting aluminum alloy, making it survive stronger wind and run more safely.
*Patented permanent magnet ac generator, effectively reduce torque, well match the wind baldes and generator, ensure the high performance of whole system.
*Controller, inverter and battery can be matched according to customers’ specific needs.
| 型号 Model | JS-H- 2000 | JS-H- 3000 | JS-H- 5000 | JS-H- 10K | JS-H- 20K | JS-H- 30K | JS-H- 50K | |
| 额定功率 Rated power | 2000W | 3000W | 5000W | 10KW | 20KW | 30KW | 50KW | |
| 额定电压 Rated voltage | 48V/96V/120V/220V/380V | 220V/380V/480V | 360V/380V/480V | |||||
| 启动风速 Start the wind speed | 2.5m/s | |||||||
| 额定风速 Rated wind speed | 11m/s | |||||||
| 安全风速 Safe wind speed | ≤50m/s | |||||||
| 叶片直径/高度 Blade diameter/height | 2.1/3.2 | 2.63*4.2 | 3.15*5 | 4.25*6.8 | 6.05*9.5 | 7.5*11.5 | 8*16 | |
| 叶片数量 Number of blades | 5片高速叶片+助动风轮 5 high-speed blades+Assist the wind wheel | |||||||
| 叶片材质 Blade material | 铝合金 Aluminum alloy | |||||||
| 主机材质 Fuselage material | 铝合金 Aluminum alloy | 铸铁 cast iron | ||||||
| 磁钢材料 Magnetic steel material | 钕铁硼NdFeB | |||||||
| 发电机类型 Generator type | 三相交流外转子发电机 Three-phase AC external rotor generator | 盘式无铁芯发电机 Disc ironless generators | ||||||
| 控制方式 Control mode | 电磁刹车 Electromagnetic brakes | |||||||
| 风向调整 Wind direction adjustment | 360°自动迎风 360° automatic windward wind | |||||||
| 寿命Service life 防护等级 Degreeofprotection | ≥20 years IP54 | |||||||
| 净重/毛重（kg） Netweight | 600/765 | 850/1150 | ||||||
| 包装尺寸（m） Packing size | 2.9*1*1.1 +4.3*0.4*0.5 | 5.1*0.5*0.6 +3.3*0.4*0.85 | ||||||
