Safety and Reliability
– Type II SPD on DC side
– AFCI function optional
High Yields
– Max. efficiency 98.4%
– Dual MPP trackers
– Wide MPPT voltage range
User Friendly
– Future proof battery ready
– Touch key and OLED display
– Compact design for one person installation
| Parameter Category | Parameter Name | MIN2500TL-X | MIN3000TL-X | MIN3600TL-X | MIN4200TL-X | MIN4600TL-X | MIN5000TL-X | MIN6000TL-X |
| PV Input Data | Max. Recommended PV Power (STC, W) | 3500 | 4200 | 5040 | 5880 | 6440 | 7000 | 8100 |
| Max. DC Voltage (V) | 500 | 500 | 550 | 550 | 550 | 550 | 550 | |
| Start Voltage (V) | 80
| |||||||
| MPP Voltage Range (V) | 80–500 | |||||||
| No. of MPP Trackers | 2
| |||||||
| No. of PV Strings per MPP Tracker | 1 | |||||||
| Max. Input Current per MPP Tracker (A) | 13.5
| |||||||
| Max. Short-Circuit Current per MPP Tracker (A) | 16.9
| |||||||
| AC Output Data | AC Nominal Power (W) | 2500 | 3000 | 3600 | 4200 | 4600 | 5000 | 6000 |
| Max. AC Apparent Power (VA) | 2500 | 3000 | 3600 | 4200 | 4600 | 5000 | 6000 | |
| Nominal AC Voltage/Range (V) | 230 (180–280) | |||||||
| AC Grid Frequency/Range | 50/60 Hz (45–55Hz/55–65Hz) | |||||||
| Max. Output Current (A) | 11.3 | 13.6 | 16 | 19 | 20.9 | 22.7 | 27.2 | |
| Total Harmonic Distortion (THDi) | <3% | |||||||
| Efficiency | Max. Efficiency | 98.2% | 98.2% | 98.2% | 98.4% | 98.4% | 98.4% | 98.4% |
| European Efficiency | 97.1% | 97.1% | 97.2% | 97.5% | 97.5% | 97.5% | 97.5% | |
| MPPT Efficiency | 99.9%
| |||||||
| Operating Conditions | Operating Temperature Range | –25°C to +60°C | ||||||
| Nighttime Power Consumption (W) | <1
| |||||||
| Relative Humidity | 0–100%
| |||||||
| Altitude | 4000m
| |||||||
| Protection Features | DC Reverse Polarity Protection | Yes | ||||||
| DC Switch | Yes
| |||||||
| AC/DC Surge Protection | Type III (DC)/Type II (AC) | |||||||
| Insulation Resistance Monitoring | Yes
| |||||||
| Ground Fault Monitoring | Yes
| |||||||
| Grid Monitoring | Yes
| |||||||
| Anti-Islanding Protection | Yes
| |||||||
| Residual-Current Monitoring Unit | Yes | |||||||
| AFCI Protection | Yes
| |||||||
| AC Short-Circuit Protection | Yes
| |||||||
| Physical Specifications | Dimensions (W×H×D, mm) | 375×350×160
| ||||||
| Weight (kg) | 10.8
| |||||||
| Noise Emission (dB(A)) | ≤35 | |||||||
| Topology | Transformerless
| |||||||
| Cooling Method | Natural Convection | |||||||
| Protection Degree (IP Rating) | IP65 | |||||||
| Connections & Interfaces | DC Connection | H4/MC4 (Optional) | ||||||
| AC Connection | Connector
| |||||||
| Display | OLED+LED/WIFI+APP
| |||||||
| Interfaces | RS485/USB/Wi-Fi/GPRS/RF/LAN (Optional)
| |||||||
| Certifications & Warranty | Warranty | 5 Years/10 Years | ||||||
| Compliance Standards | CE, IEC62109, VDE0126-1-1, AS4777, AS/NZS 3100, VDE-AR-N4105, CQC, IEC61683, IEC60068, IEC61727, IEC62116, INMETRO | |||||||
